TO220-3/TO263-3 VOLTAGE REGULATOR
EVALUATION BOARD USER ’S GUIDE
Appendix B. Bill of Materials (BOM)
TABLE B-1:
BILL OF MATERIALS (BOM)
Qty
Reference
Description
Manufacturer
Part Number
1
1
C1
C2
CAP CERAMIC 1.0 uF 50V X7R 0805 Murata Electronics ?
CAP CERAMIC 1.0 uF 16V X7R 0805 Kemet ? Electronics
GRM21BR71H105KA12L
C0805C105K4RACTU
1
1
C3
J1
DO NOT POPULATE
2 pin RA header, 0.100 centers,
—
3M
—
929835-01-36-RK
0.025 sq pins, 0.070 pcb to pin center
height, 36 pins to a strip (yields 18
headers)
4
JP1, JP3, JP4,
2 pin header, 0.100 centers, 0.025 sq
Molex ? Electronics
22-28-4360
JP5
pins, 0.070
4
JP1, JP3, JP4,
Connector, Jumper Shorting, Tin
Sullins Electronics
STC02SYAN
JP5
1
P1
RA socket, 0.100 centers,
Sullins Electronics
PPPC021LGBN-RC
0.025 sq pins, 0.070 pcb to pin center
height
1
PCB
RoHS Compliant Bare PCB, TO220-3 Microchip Technology 104-000204
/ TO263-3 Voltage Regulator Evalua-
Inc.
tion Board
2
8
R5, R6
TP1, TP2, TP3,
TP4, TP6, TP7,
DO NOT POPULATE
SMT Testpoint
—
Keystone
Electronics ?
—
5016
TP9, TP10
2
U1, U2
DO NOT POPULATE
—
—
4
On Each Corner Bumpon Hemisphere, 0.44 x 0.20,
3M
SJ-5003 (BLACK)
Black
Note 1:
The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM
used in manufacturing uses all RoHS-compliant components.
? 2009 Microchip Technology Inc.
DS51818A-page 15
